Mesh Fencing
Galvanized & PVC-coated fencing
Overview
Chain link fence is a woven diamond-mesh fence made from galvanized steel wire, with an optional PVC coating over the zinc for extra protection against rust. It suits everything from farm boundaries to high-security perimeters, keeping people and animals out while leaving a clear view through the fence. The fabric ships in compact rolls and is stretched between posts on site.
Where it is used
Modular clamping fittings mean no welding or fabrication on site, which keeps installation quick and costs down.
The fabric can be stretched over uneven or hilly ground.
Compact rolls are simple to carry and handle.
Several coating options let you match the fence to the corrosion conditions at the site.
The top and bottom edges can be knuckled, twisted, or one of each, depending on the security level needed.
Choose the mesh opening to suit the application and security requirement.
Clear visibility from both sides of the fence.
Galvanizing and the optional PVC coating keep rusting to a minimum.
| Parameter | Details |
|---|---|
| Mesh size | 50 x 50, 65 x 65, 75 x 75, 100 x 100 mm |
| Wire diameter, galvanized | 2.0 – 4.0 mm; commonly 2.5 mm (12 gauge) or 3.0 mm (10 gauge) |
| Wire diameter, PVC-coated | 1.40 mm core / 2.00 mm overall, up to 4.00 mm core / 5.00 mm overall |
| Roll length | Typically 10 – 30 m (about 33 – 98 ft); shorter rolls for taller or heavier fabric |
| Height | Made to order |
| Zinc coating | Up to 275 GSM heavy galvanized |
| Edge finish (top and bottom) | Knuckled or twisted, in any combination |
